OpenFlex Data24 NVMe-oF Storage Platform
Designed for high performanceThe OpenFlex Data24 NVMe-oF Storage Platform extends the high performance of NVMe flash to shared storage. It provides low-latency sharing of NVMe SSDs over a high-performance Ethernet fabric to deliver similar performance to locally attached NVMe SSDs. Industry-leading connectivity, using Western Digital RapidFlex™ network adapters, allows up to six hosts to be attached without a switch.
The OpenFlex Data24 NVMe-oF Storage Platform can also be used as a disaggregated storage resource in an open composable infrastructure environment. OpenFlex Data24 is built to deliver high availability and enterprise-class reliability.
Highlights
- High density and capacity
- Up to 368TB in 2U
- Low latency
- Dual Port SSDs
- Bandwidth match between SSDs (Storage) and I/O (Network) - No oversubscription
- RESTful API support for simplified management
- Superior serviceability and high quality global support services
- 5-year limited warranty
Applications and Workloads
- Real-time Analytics
- Database
- SDS Environments
- High-Performance Computing
- Public or Private Cloud
- Virtualization
- Scale-Out/Up Configurations
- AI and Machine Learning
Specifications
| Form Factor | 2U |
| Front Drive Bays | Up to 24 x U.2 NVMe SSDs |
| Power Supply | 2x 2000W Platinum 200-240VAC, CRPS, Hot Plug |
| Fabric Adapter Slots | 6x PCIe x16 |
| Fabric Adapter(s) | Western Digital RapidFlex NVMe-oF Fabric Adapter |
| Cabling | Passive (1 - 5M) and Active Optical (5 - 50M) |
| Platform Management | ARM based BMC |
| Rear I/O | 1G-BASE-T Management Port (RJ-45) |
| HA Redundancy | Dual IOMs, Dual Port SSDs, Dual PSUs, Dual Rotor Hot Plug fans |
| Environmental | 10°C - 35°C |
|
Chassis Dimensions (Height x Width x Depth) |
8.75 x 44.80 x 71.12 cm
3.45" x 17.64" x 28" in |
| Weight | Maximum 31.75 kg / 70 lb |
| Limited Warranty | 5 years standard |
