Dell PowerEdge T560 Tower Server | ASA Computers

Dell PowerEdge T560 Tower Server

Dell PowerEdge T560 Tower Server

  • Up to two 4th Gen Intel® Xeon Scalable processor, with up to 32 cores per processor or up to two 5th Gen Intel® Xeon Scalable processor, with up to 28 cores per processor

  • Up to 6 NVIDIA A2 or L4 GPUs

  • Up to 24 x 2.5-inch SAS/SATA HDD drives, max 360 TB or up to 8 x 3.5-inch SAS/ SATA HDD + 8 x 2.5-inch NVMe SSD drives, max 240 TB

  • Up to 6 x PCIe slots

Request Info

Features

Faster, more Powerful, and Balanced

The Dell PowerEdge T560 Tower Server provides exceptional performance and adaptability for medium-to-large businesses. Designed for various high-performance applications, its tower form factor supports both flexibility and powerful processing capabilities.

Great for:

  • Data-intensive applications and analytics
  • Virtualization and cloud deployments
  • Large-scale database management
  • High-performance computing tasks
  • AI inferencing

Scale Seamlessly to Meet Evolving IT Needs with Extensive Flexibility

Designed to adapt to changing business requirements, the PowerEdge T560 allows for easy scaling and optimization of resources.

  • Support for advanced AI-driven performance tuning to automatically adjust for optimal efficiency.
  • Easily expand storage and compute resources to accommodate growing data and workload demands.
  • Upgrade or add components with a modular design to keep pace with technological advancements.

Maximize Operational Efficiency with Automated Management Tools

Dell OpenManage simplifies server management and maintenance, allowing IT teams to focus on strategic tasks.

  • Reduce downtime and troubleshooting efforts with ProSupport Plus and SupportAssist, which can cut issue resolution time by up to 72%.
  • Integrate smoothly with existing management tools such as VMWare vSphere, Microsoft System Center, and Nagios.
  • Expedite server setup with OpenManage%apos;s streamlined configuration and deployment tools.
  • Access and manage server functions remotely via the OpenManage Mobile app.

Ensure Robust Data Protection with Integrated Security Measures

The PowerEdge T560 features a comprehensive security framework to protect against threats and ensure data integrity.

  • Secure server settings and firmware with Configuration Lock-down to prevent unauthorized changes.
  • Implement system erase to safeguard data privacy when decommissioning or repurposing hardware.
  • Automate firmware updates with dependency checks and sequence validation to ensure safe and effective deployments.
  • Use Secure Boot to defend against malware attacks and ensure only trusted firmware is loaded.
  • Monitor and address potential security issues with iDRAC9 for secure remote management.

Tech Specs & Customization

Processor
Processor
Up to two 4th Generation Intel® Xeon® Scalable processors, up to 32 cores per processor
Up to two 5th Generation Intel® Xeon® Scalable processor,
with up to 28 cores per processor
Operating Systems
Supported Operating Systems
Canonical® Ubuntu® Server LTS
Citrix® Hypervisor ®
Microsoft® Windows Server® with Hyper-V
Red Hat® Enterprise Linux
SUSE® Linux Enterprise Server
VMware® ESXi®
Bezel
Bezel
Optional security bezel
Dimensions
Width
200.0mm (7.87")
Depth
678.2 mm (26.70") (with bezel)
660.6 mm (26") (without bezel)
Height
464.0 mm (18.26") (with feet)
508.8 mm (20.03") (with caster wheels)
446.0 mm (17.60") (without feet)
Memory*
DIMM Speed
Up to 4800 MT/s on the 4th Generation Intel® Xeon Scalable processor
Up to 5200 MT/s on the 5th Generation Intel® Xeon Scalable processor
Memory Type
RDIMM
Memory Module Slots
16 DDR5 DIMM slots
Supports registered ECC DDR5 DIMMs only
Maximum RAM
1TB
Management
Embedded Management
iDRAC9
iDRAC Direct
iDRAC RESTful API with Redfish
iDRAC Service Module
Quick Sync 2 wireless module
OpenManage Software
OpenManage Enterprise
OpenManage Power Manager plugin
OpenManage Service plugin
OpenManage Update Manager plugin
CloudIQ for PowerEdge plug in
OpenManage Enterprise Integration for VMware vCenter
OpenManage Integration for Microsoft System Center
OpenManage Integration with Windows Admin Center
Mobility
OpenManage Mobile
OpenManage Integrations
BMC® Truesight
Microsoft® System Center
OpenManage Integration with ServiceNow
RedHat® Ansible® Modules
Terraform Providers
VMware® vCenter and vRealize Operations Manage
Power Supplies
Power Supplies
600 W Platinum 100-240 VAC/240 VDC
700 W Titanium 200-240 VAC/240 VDC
800 W Platinum 100-240 VAC/240 VDC
1100 W Titanium 100-240 VAC/240 VDC
1100 W DC/-48-(-60) V
1400 W Platinum 100-240 VAC/240 VDC
1400 W Titanium 100-240 VAC/240 VDC
1400 W Titanium 277 VAC/336 VDC
1800 W Titanium 200-240 VAC/240 VDC
2400 W Platinum 100-240 VAC/240 VDC
2800 W Titanium 200-240 VAC/240 VDC
GPU
GPU Options
Up to 2 x 300 W DW or 6 x 75 W SW
Security
Front Bays
Cryptographically signed firmware
Data at Rest Encryption (SEDs with local or external key mgmt)
Secure Boot
Secure Erase
Secured Component Verification (Hardware integrity check)
Silicon Root of Trust
System Lockdown (requires iDRAC9 Enterprise or Datacenter)
TPM 2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ
Storage Controller
Internal PERC
fPERC H965i, fPERC H755N, fPERC H755, fPERC H355, fPERC HBA355i, HBA465i fPERC
Internal Boot
Boot Optimized Storage Subsystem (BOSS-N1): HWRAID 2 x M.2 NVMe SSD drives, or USB
External HBA (non-RAID)
PERC HBA355e
Software RAID
S160 (for NVMe drives only)
Recommended Support
Recommended Support
Maximize your PowerEdge Servers with comprehensive services ranging from Consulting, to ProDeploy and ProSupport suites, Data Migration and more – available across 170 countries and backed by our 60K+ employees and partners.
Slots
PCie
Up to six PCIe slots:
Slot 1: x16 Gen5 Full height, Full length
Slot 2: x16 Gen5 Full height, Full length
Slot 3: x16 Gen4 Full height, Half length
Slot 4: x16 Gen4 Full height, Half length
Slot 5: x16 (x8 lanes) Gen4 Full height, Half length
Slot 6: x16 Gen4 Full height, Half length
Form Factor
Form Factor
4.5U tower server
Storage
Front Bays
Up to 12 x 3.5-inch SAS/SATA HDD drives, max 180 TB
Up to 8 x 3.5-inch SAS/SATA HDD drives, max 120 TB
Up to 8 x 3.5-inch SAS/ SATA HDD + 8 x 2.5-inch NVMe SSD drives, max 240 TB
Up to 8 x 2.5-inch SAS/SATA HDD drives, max 120 TB
Up to 16 x 2.5-inch SAS/SATA HDD drives, max 240 TB
Up to 24 x 2.5-inch SAS/SATA HDD drives, max 360 TB
Ports
Network Options
1 x OCP x8 card 3.0
Embedded NIC: 2 x 1GbE LOM on Planar
Front Ports
1 x USB 2.0
1 x USB 3.0
1 x iDRAC Direct (Micro-AB USB) port
Rear Ports
1 x USB 2.0
1 x USB 3.0
1 x Serial port (optional)
1 x Dedicated iDRAC (RJ45) port
1 x VGA port
2 x Ethernet ports
