Dell PowerEdge T550 Tower Server

Dell PowerEdge T550 Tower Server

  • Up to two 3rd Gen Intel® Xeon Scalable processors, with up to 36 cores per processor

  • Up to two NVIDIA A40, or five NVIDIA T4 GPUs

  • Up to 24 x 2.5-inch SAS/SATA (HDD) max 360 TB or up to 8 x 3.5-inch SAS/SATA (HDD) + 8 x 2.5-inch NVMe (SSD) max 240 TB

  • Up to 6 x PCIe Gen4 slots

Request Info

Features

Expandable Tower Server for Enterprise Workloads Outside the Data Center

Powered by 3rd Gen Intel Xeon Scalable processors, the PowerEdge T550 is optimized for data-intensive workloads and balances higher performance technology with a quieter, management-friendly enclosure, making it the ideal Tower Server for virtualization, database and analytics, and AI/ML inferencing.

Great for:

  • Virtualization and Cloud Computing
  • AI/ML and Inference
  • Business Analytics and Intelligence
  • Database Management
  • High Performance Computing (HPC) Workloads

Scale and Adapt to Evolving Business Needs with Enhanced Flexibility

Designed to grow with you, the PowerEdge T550 server is built on a scalable business architecture so you can continually optimize your performance and capacity. Outstanding efficiency helps you keep operating expenses in check as your requirements evolve.

  • Scale compute resources with 3rd Generation Intel® Xeon® Scalable processors and a new memory architecture.
  • Automatically optimize application performance with one-button tuning.
  • Grow data over time with up to 8 x 3.5" or 16 x 2.5" drives.
  • Boost I/O performance with up to 8 PCIe Gen4 I/O slots.

OpenManage systems management

The Dell Technologies OpenManage systems management portfolio helps tame the complexity of your IT environment with tools and solutions to discover, monitor, manage, update, and deploy your PowerEdge infrastructure.

Built-in security

PowerEdge servers are made with a cyber resilient architecture that builds in security at every phase of the product lifecycle, from the silicon root of trust and secured component verification, to signed firmware and drift detection, to BIOS recovery.

Tech Specs & Customization

Processor
Processor
Up to two 3rd Generation Intel® Xeon® Scalable processors, up to 36 cores per processor
Operating Systems
Supported Operating Systems
Canonical® Ubuntu® Server LTS
Citrix® Hypervisor ®
Microsoft® Windows Server® with Hyper-V
Red Hat® Enterprise Linux
SUSE® Linux Enterprise Server
VMware® ESXi®
Bezel
Bezel
Optional security bezel
Dimensions
Width
200.0mm (7.87")
Depth
663.5mm (26.12") without bezel
680.5mm (26.79") with bezel
Height
459.0mm (18.07")
Memory
DIMM Speed
Up to 3200 MT/s
Memory Type
RDIMM
Memory Module Slots
16 DDR4 DIMM slots
Supports registered ECC DDR4 DIMMs only
Maximum RAM
RDIMM 1TB
Management
Embedded / At-the-Server
iDRAC9
iDRAC Direct
iDRAC RESTful API with Redfish
Quick Sync 2 wireless module
Consoles
OpenManage Enterprise
OpenManage Power Manager plugin
OpenManage SupportAssist plugin
OpenManage Update Manager plugin
Mobility
OpenManage Mobile
OpenManage Integrations
BMC® Truesight
Microsoft® System Center
RedHat® Ansible® Modules
VMware® vCenter
OpenManage Connections
IBM Tivoli® Netcool/OMNIbus
IBM Tivoli® Network manager IP Edition
Micro Focus® Operations Manager I
Nagios® Core
Nagios® XI
Power Supplies
Power Supplies
600W Platinum Mixed Mode (100-240Vac or 240Vdc)
700W Titanium Mixed Mode (200-240Vac or 240Vdc)
800W Platinum Mixed Mode (100-240Vac or 240Vdc)
1100W -48Vdc to -60Vdc
1100 W Titanium Mixed Mode (100-240Vac or 240Vdc)
1400 W Platinum Mixed Mode (100-240Vac or 240Vdc)
1800 W Titanium Mixed Mode (200-240Vac or 240Vdc)
2400 W Platinum Mixed Mode (100-240Vac or 240Vdc)
GPU
GPU Options
Up to two double wide 300 W NVIDIA A40, or
five single wide 70 W NVIDIA T4
Security
Cryptographically signed firmware
Secure Boot
Secure Erase
Silicon Root of Trust
System Lockdown (requires iDRAC9 Enterprise or Datacenter)
TPM 1.2/2.0, CC-TCG certified, TPM 2.0 China NationZ
Storage Controller
Internal Controllers
HBA345, PERC H345, PERC H355, PERC H745, PERC H755, S150, H755N, HBA355i
Internal Boot
Internal Dual SD Module
Boot Optimized Storage Subsystem (BOSS-S2)
HWRAID 2 x M.2 SSDs, USB
External PERC (RAID)
PERC H840
External HBAs (non-RAID)
HBA355e
Recommended Support
Recommended Support
Choose Dell ProSupport Plus for critical systems or Dell ProSupport for premium hardware and software support for your PowerEdge solution. Consulting and deployment offerings are also available. Contact your Dell representative today for more information. Availability and terms of Dell Services vary by region.
Slots
PCie
Up to 6 x PCIe Gen4 slots
Form Factor
Form Factor
5U Tower Server
Storage
Front Bays
Up to 8 x 2.5-inch SAS/SATA (HDD) max 120 TB
Up to 16 x 2.5-inch SAS/SATA (HDD) max 240 TB
Up to 24 x 2.5-inch SAS/SATA (HDD) max 360 TB
Up to 8 x 3.5-inch SAS/SATA (HDD/SAS) max 120 TB
Up to 8 x 3.5-inch SAS/SATA (HDD)
+ 8 x 2.5-inch NVMe (SSD) max 240 TB
Ports
Network Options
1 x OCP 3.0
Front Ports
1 x iDRAC Direct (Micro-AB USB) port (optional)
1 x USB 2.0
1 x USB 3.0 (optional)
Rear Ports
1 x iDRAC Direct (Micro-AB USB) port
1 x Serial (optional)
1 x USB 3.0
2 x Ethernet
1 x VGA
