Dell PowerEdge R760xs Server

Dell PowerEdge R760xs Server

The best choice for the right balance in performance in an air-cooled chassis for the most popular IT applications.

  • 2U rack server

  • Virtual Desktop Infrastructure (VDI) - Virtual Machines (VMs) - Software-Defined Storage Node

  • Up to 2 x 5th generation Intel® Xeon® Scalable processors with up to 28 cores and 4th generation Intel® Xeon® Scalable processors with up to 32 cores per processor

  • Up to 12 x 3.5-inch SAS/SATA (HDD/SSD) max 288 TB

  • 16 DDR5 DIMM slots, supports RDIMM 1.5 TB max, speeds up to 5200 MT/s, supports registered ECC DDR5 DIMMs only

Request Info

Features

Performance And Versatility

Gain the performance you need with Dell PowerEdge R760xs which is designed to optimize even the most demanding workloads like AI, dense database analytics and high-density virtualization.

Autonomous Infrastructure

Tame the complexity of your IT environment with Dell Technologies OpenManage systems management portfolio which uses tools and solutions to discover, deploy, monitor, manage, update and secure your PowerEdge infrastructure.

Cyber Resilient Architecture

Ensure protection at every stage of the product lifecycle with the PowerEdge cyber-resilient architecture, designed to support your journey toward a Zero Trust security strategy.

Tech Specs & Customization

Processor
Processor
Up to two 5th Generation Intel Xeon Scalable processor with up to 28 cores and 4th Generation Intel Xeon
Scalable processor with up to 32 cores per processor
Operating Systems
Supported Operating Systems
Canonical® Ubuntu® Server LTS
Microsoft® Windows Server® with Hyper-V
Red Hat® Enterprise Linux
SUSE® Linux Enterprise Server
VMware® ESXi®
Bezel
Bezel
Optional LCD bezel or security bezel
Dimensions
Width
482.0mm (18.97")
Depth
707.78mm (27.85") without bezel
721.62mm (28.4") with bezel
Height
86.8mm (3.41")
Memory
DIMM Speed
16 DDR5 DIMM slots, supports RDIMM 1.5 TB max, speeds up to 5200 MT/s
Memory Module Slots
Supports registered ECC DDR5 DIMMs only
Management
Embedded / At-the-Server
iDRAC9
iDRAC Direct
iDRAC RESTful API with Redfish
iDRAC Service Module
Quick Sync 2 wireless module
Consoles
OpenManage Enterprise
OpenManage Power Manager plugin
OpenManage Service plugin
OpenManage Update Manager plugin
CloudIQ for PowerEdge plug in
OpenManage Enterprise Integration for VMware vCenter
OpenManage Integration for Microsoft System Center
OpenManage Integration with Windows Admin Center
Mobility
OpenManage Mobile
OpenManage Integrations
BMC® Truesight
Microsoft® System Center
OpenManage Integration with ServiceNow
RedHat® Ansible® Modules
Terraform Providers
VMware® vCenter and vRealize Operations Manager
Power Supplies
Power Supplies
(All are hot swap with full redundancy)
1800 W Titanium 200-240 VAC or 240 VDC
1400 W Titanium 100-240 VAC or 240 VDC
1400 W Platinum 100-240 VAC or 240 VDC
1400 W Titanium 277 VAC or HVDC
(HVDC stands for HighVoltage DC, with 336V DC)
1100 W Titanium 100-240 VAC or 240 VDC
1100 W -(48V - 60V) DC
800 W Platinum 100-240 VAC or 240 VDC
700 W Titanium 200-240 VAC or 240 VDC
600 W Platinum 100-240 VAC or 240 VDC
GPU
GPU Options
2 x 75 W SW, LP
Security
Cryptographically signed firmware
Data at Rest Encryption (SEDs with local or external key mgmt)
Secure Boot
Secured Component Verification (Hardware integrity check)
Secure Erase
Silicon Root of Trust
System Lockdown (requires iDRAC9 Enterprise or Datacenter)
TPM 2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ
Storage Controller
Internal Controllers (RAID)
PERC H965i, PERC H755, PERC H755N, PERC H355, HBA355i, HBA465i
Internal Boot
Boot Optimized Storage Subsystem (BOSS-N1)
HWRAID 1, 2 x M.2 NVMe SSDs or USB
External HBA (non-RAID)
HBA355e; Software RAID: S160
Slots
PCie (1 CPU)
Up to 4 PCIe slots
2 x8 Gen5, 1 x16 Gen4, 1 x8 Gen4
PCie (2 CPUs)
Up to 6 PCIe slots
2 x16 Gen5, 3 x16 Gen4, 1 x8 Gen4
Form Factor
Form Factor
2U Rack Server
Storage
Front Bays
0 drive bay
Up to 8 x 3.5-inch SAS/SATA (HDD/SSD) max 192 TB
Up to 12 x 3.5-inch SAS/SATA (HDD/SSD) max 288 TB
Up to 8 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 122.88 TB
Up to 16 x 2.5-inch SAS/SATA (HDD/SSD) max 121.6 TB
Up to 16 x 2.5-inch (SAS/SATA) + 8 x 2.5-inch (NVMe)
(HDD/SSD) max 244.48 TB
Rear Bays
Up to 2 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 30.72 TB
(supported only with 12 x 3.5-inch SAS/SATA HDD/SSD
configuration)
Ports
Front Ports
1 x iDRAC Direct (Micro-AB USB) port
1 x USB 2.0
1 x VGA
Rear Ports
1 x Dedicated iDRAC Ethernet port
1 x USB 3.0
1 x USB 2.0
1 x USB 3.0
1 x Serial (optional)
1 x VGA
Internal Ports
1 x USB 3.0 (optional)
