Dell PowerEdge R6615 Server

Dell PowerEdge R6615 Server

1 x AMD EPYC 4th Generation 9004 Series with up to 128 cores per processor
12 DDR5 DIMM slots, supports RDIMM 3 TB max, speed up to 4800 MT/s
Up to 4 x 3.5-inch SAS/SATA (HDD/SSD) max 80 TB or other configurations
Up to 2 NVIDIA Ampere A2, L4 GPUs
Supports air or optional Direct Liquid Cooling

Request Info

Product Detail
Tech Specs & Customization

Features

Flexible For Any Workload

Maximize performance and investment efficiency with this 1U single-socket server, designed for both traditional and emerging workloads. Ideal for dense virtualization, hyper-converged infrastructure (HCI), and Network Function Virtualization (NFV) using OpenStack for Telco.

Autonomous Infrastructure

Tame the complexity of your IT environment with Dell Technologies OpenManage systems management portfolio which uses tools and solutions to discover, deploy, monitor, manage, update and secure your PowerEdge infrastructure.

Dell PowerEdge R6615 Rack Server Software UI

Cyber Resilient Architecture

Ensure protection at every stage of the product lifecycle with the PowerEdge cyber-resilient architecture, designed to support your journey toward a Zero Trust security strategy.

Tech Specs & Customization

Processor

One AMD EPYC 4th Generation 9004 Series with up to 128 cores

Operating Systems

Supported Operating Systems

Canonical® Ubuntu® Server LTS
Citrix® Hypervisor ®
Microsoft® Windows Server® with Hyper-V
Red Hat® Enterprise Linux

SUSE® Linux Enterprise Server

VMware® ESXi®

Bezel

Optional security bezel

Dimensions

Width

482.0mm (18.97")

Depth

809.05mm (31.85") without bezel
822.89mm (32.39") with bezel

Height

42.8mm (1.685")

Memory

DIMM Speed

12 DDR5 DIMM slots, supports RDIMM 3 TB max, speed up to 4800 MT/s

Memory Module Slots

Supports registered ECC DDR5 DIMMs only

Management

Embedded / At-the-Server

iDRAC9
iDRAC Direct
iDRAC RESTful API with Redfish

iDRAC Service Module

Quick Sync 2 wireless module

Consoles

OpenManage Enterprise
OpenManage Power Manager plugin

OpenManage Service plugin

OpenManage Update Manager plugin

CloudIQ for PowerEdge plug in

OpenManage Enterprise Integration for VMware vCenter

OpenManage Integration for Microsoft System Center

OpenManage Integration with Windows Admin Center

Mobility

OpenManage Mobile

OpenManage Integrations

BMC® Truesight
Microsoft® System Center
OpenManage Integration with Windows Admin Center

RedHat® Ansible® Modules

Terraform Providers

VMware® vCenter and vRealize Operations Manager

Power Supplies

(All are hot swap redundant)
1800 W Titanium 200-240 V AC or 240 HVDC
1400 W Platinum 100-240 V AC or 240 HVDC

1400 W Titanium 277 V AC or 336 HVDC

1100 W Titanium 100-240 V AC or 240 HVDC

1100 W LVDC -48 - -60 VDC

800 W Platinum 100-240 V AC or 240 HVDC

700 W Titanium 200-240 V AC or 240 HVDC

GPU

GPU Options

Up to 2 x 75 W SW

Security

AMD Secure Encrypted Virtualization (SEV)

AMD Secure Memory Encryption (SME)

Cryptographically signed firmware

Data at Rest Encryption (SEDs with local or external key mgmt)

Secure Boot

Secured Component Verification (Hardware integrity check)

Secure Erase

Silicon Root of Trust

System Lockdown (requires iDRAC9 Enterprise or Datacenter)

TPM 2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ

Storage Controller

Internal Controllers (RAID)

PERC H965i, PERC H755, PERC H755N, PERC H355, HBA355i

Internal Boot

Internal Dual SD Module
Boot Optimized Storage Subsystem (BOSS-N1)

HWRAID 2 x M.2 NVMe SSDs or USB

External HBA (non-RAID)

HBA355e

Software RAID

S160

Slots

PCie

Up to three PCIe slots

Slot 1

1 x16 Gen5 or 1 x16 Gen4 Low profile, Half length or
1 x16 Gen5 Full height, Half length or

1 x8 Gen4 Low profile, Half length

Slot 2

1 x16 Gen4 Low profile, Half length or
1 x16 Gen5 Full height, Half length or

1 x8 Gen4 Low profile, Half length

Slot 3

1 x16 Gen5 or 1 x16 Gen4 Low profile, Half length

Form Factor

1U Rack Server

Storage

Front Bays

Up to 4 x 3.5-inch SAS/SATA (HDD/SSD) max 80 TB
Up to 8 x 2.5-inch NVMe (SSD) max 122.88 TB

Up to 10 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 153.6 TB

Up to 14 x EDSFF E3.S Gen5 NVMe (SSD) max 107.52 TB

Up to 16 x EDSFF E3.S Gen5 NVMe (SSD) max 122.88 TB

Rear Bays

Up to 2 x 2.5-inch SAS/SATA (HDD/SSD) max 30.72 TB
Up to 2 x EDSFF E3.S Gen5 NVMe (SSD) max 15.36 TB

Ports

Front Ports

1 x iDRAC Direct (Micro-AB USB) port
1 x USB 2.0

1 x VGA

Rear Ports

1 x Dedicated iDRAC Ethernet port
1 x USB 3.0

1 x USB 2.0

1 x Serial (optional)

1 x VGA (optional for Direct Liquid Cooling configuration)

Internal Ports

1 x USB 3.0 (optional)
